ENGLISH
Installation Manual
8
Step 3
Move the range indoors before installing the legs,
legs are not suitable for moving the appliance over
long distances.
Legs are packed in the cardboard top pack.
CAUTION
Doors and passageways leading to the installation
location require at least 31” opening. If the
opening is less than 31”, the oven door(s) and
control knobs must be removed.
(see Use & Care manual for oven door removal
instructions).
Note: the legs with collar must be mounted on
the back of range to engage the anti tip device.
Step 4
With the foam base still in place, tilt the range laterally
"
Step 5
Pull out the hand-truck, tilt the range laterally and
insert the second pair of legs. Remove the base
Step 6
Install the backsplash (if provided) by the three
screws on the back and the toe kick
9”
3”
Step 7
After the electrical and gas connections (see both
paragraphs for instructions) measure the four corners
!!?@
leveling legs to the desired height and ensure range
is level. Turn the bottom section of each leg counter-
clockwise to raise the leg and clock wise to lower
K X
making sure to engage the anti-tip bracket.
Step 8
Push toekick against the range until clip snaps to
NOTE: Be sure the toekick snaps securely.
