9. Attach one end of the Linkage Tube (#8) to the inside of
the Curved Outer Leg (#5) using one Bolt (#A2), two
Washers (#A4), one Spacer (#A5) and one Nut (#A6).
See FIG. 3A.
10. Repeat the same for the other end of this Linkage
Tube, only attaching it to the outside of the Curved
Inner Leg (#6).
11. Attach one end of the Linkage Tube with Stop Bracket
(#7) to the inside of the Curved Outer Leg (#5) using
one Bolt (#A2), two Washers (#A4), one Spacer (#A5)
and one Nut (#A6).
12. Repeat the same for the other end of this Linkage
Tube, only attaching it to the outside of the Curved
Inner Leg (#6). See FIG. 3B.
13. Repeat the above steps for the other table half.
5
8
8
7
7
5
6
6
A4
A8
A9
A5
A5
A6
A6
A4
A2
A2
A4 A4
FIG. 3A
FIG. 3B
Player
Player
Center
Note: Be careful of the assembly
direction on pictures when you
assemble the Linkage Tube #7 and
#8 in order to fit the folding function.
