20

Check door strike alignment

11.

Close door and check that door strike aligns with door catch.

If it is needed, slide door catch left or right within slot to

adjust alignment.

Insert screws in hinge holes on

dryer cabinet

10.

NOTE: 2 people may be needed to reinstall door.

Insert screws into the bottom holes on left side of dryer

cabinet. Tighten screws halfway. Position door so large end of

door hinge slot is over screws. Slide door up so screws are in

bottom of slots. Tighten screws. Insert and tighten top screws

in hinges.

27" Wide Model Side-Swing Door with Glass

Place towel on dryer

1.

Place towel on top of dryer to avoid damaging the surface.

Lift door until top screws in dryer cabinet are in large part of

hinge slot. Pull door forward off screws. Set door (handle side

up) on top of dryer. Remove top screws from dryer cabinet.

Lift door off top screws

3.

Remove bottom screws

2.

Open dryer door. Remove bottom screws from dryer cabinet

side of hinges. Loosen (do not remove) top screws from dryer

cabinet side of hinges.

Remove screws attaching hinges to door.

Remove screws from hinges

4.
