Maytag WGD4890XQ Installation - Manuel (Page 17)

17
Flip door over
7.
Flip door over so handle side is down.
Attach door hinges
8.
Reattach door hinges to dryer door so that the larger hole is
at the bottom of the hinge.
Insert screws in hinge holes on
dryer cabinet
11.
NOTE: Two people may be needed to reinstall door.
Insert screws into the bottom holes on left side of dryer
cabinet. Tighten screws halfway. Position door so large end
of door hinge slot is over screws. Slide door up so screws
are in bottom of slots. Tighten screws. Insert and tighten top
screws in hinges.
Remove door strike from dryer cabinet and set aside.
Remove door strike
9.
Use a small, flat-blade screwdriver to gently remove 4 hinge
hole plugs on left side of dryer cabinet. Transfer plugs into
hinge holes on opposite side of dryer cabinet.
Remove and transfer hinge
hole plugs
10.
