9-4. COMMANDS AND RESPONSES TABLE (continued)
ASCII RESPONSE COMMAND TYPE VALUE
COMMAND DESCRIPTION MIN MAX DESCRIPTION
STATUS COMMANDS
U UNIT Measures unity in kHz. Rd 0 65535
IL ILD
This command allows to calculate the
input line frequency in Hz.
Rd 0 65535 Line frequency (in kHz) = (UNIT VALUE) ÷
(ILD VALUE).
ID IFD
This command allows to calculate the
input frame frequency in Hz.
Rd 0 65535
Frame frequency (in Hz) = (Line frequency in
Hz)
÷ (IFD VALUE).
IP IPS Input Sync. detection. Rd 0 1 0 = not detected 1 = Sync. detected.
IH IHP Sign of the horizontal input Sync. Rd 0 1 0 = negative 1 = positive.
IV IVP Sign of the vertical input Sync. Rd 0 1 0 = negative 1 = positive.
IK IST Input Sync type detection. Rd 0 3
0 = H &V. 2 = SOG.
1 = Composite (TTL). 3 = Composite (ana)
II IIN Interlaced signal detection. Rd 0 1 0 = not interlaced 1 = interlaced.
IO IOO "Out of range" signal detection. Rd 0 1 0 = In range 1 = Out of range.
IF IFA Standard input signal detection. Rd 0 27
XF REFF Standard of the reference input. Rd 0 27
0 = no signal. 1 = not compatible.
2 = NTSC (3.58/60). 3 = NTSC (4.43/60).
4 = PAL (4.43/50). 5 = PAL (4.43/60).
6 = SECAM (50Hz). 7 = B & white (50Hz).
8 = B & white (60Hz). 9 = YUV 50 Hz.
10 = YUV 60 Hz.
11 = RGB 50 Hz.
12 = RGB 60 Hz. 13 = VGA1 350L.
14 = VGA2 400L. 15 = VGA3 480L.
16 = PLASMA 42". 17 = SVGA.
18 = MAC. 19 = XGA.
20 = PLASMA 50'. 21 = MAC 21'.
22 = SXGA. 23 = UXGA.
24 = 1080i @ 50 Hz. 25 = 1080i @59.94/60.
26 = 480p @ 59.94/60. 27 = 720p @ 59.94/60.
XT REFT Frame frequency of the reference input Rd 0 65535 Value in Hz.
COMMUNICATION PORT COMMANDS
ne LANE Communication port selection Rd/Wr 0 1 0 = RS232 1 = LAN
nr LANR Reset of the LAN parameters. Rd/Wr 0 1 1 = reset.
ns LANS Store the LAN parameters. Rd/Wr 0 1 1 = store.
na ADIP
IP address and port selection (for
modification)
Rd/Wr 0 3
0 = all IP address / ports
1 = IP local address / local port
2 = IP remote address / remote port
3 = IP gateway address.
nw IPA_
First byte of the address selected by the
na command.
Rd/Wr 0 255
nx IPB_
Second byte of the address selected by
the na command.
Rd/Wr 0 255
ny IPC_
Third byte of the address selected by the
na command.
Rd/Wr 0 255
nz IPD_
Forth byte of the address selected by the
na command.
Rd/Wr 0 255
np PORT
Number of the port (local or remote)
selected by the na command.
Rd/Wr 0 65500
local port: 10000 to 10999.
remote port: 0 to 65500.
nk NTMK Netmask. Rd/Wr 0 24
Value = number of bit to 0 (from right).
example: 2 255.255.255.252
3
255.255.255.248
.............
8
255.255.255.0
.............
24
255.0.0.0
nt TCP Protocol selection. Rd/Wr 0 1 0 = UDP 1 = TCP
NOTE: * = command available on the OCTO-FADE ™ & OCTO-FX ™ only. Rd = Read only command.
** = command available on the OCTO-LOGO ™ & OCTO-FX ™ only. Rd/Wr = Read and write command.
