Chapter 9 : REMOTE CONTROL PROGRAMMER'S GUIDE (continued) OCTO range
PAGE 34
9-4. COMMANDS AND RESPONSES TABLE
The following table resumes commands that are recognized as valid and the responses that will be returned to the control
device (on RS-232 port).
ASCII RESPONSE COMMAND TYPE VALUE
COMMAND DESCRIPTION MIN MAX DESCRIPTION
FRONT PANEL COMMANDS
C CH Selected input. Rd 1 8
c ch Input selection. Rd/Wr 1 8
1 = INPUT #1 2 = INPUT #2
3 = INPUT #3 4 = INPUT #4
5 = INPUT #5 6 = INPUT #6
7 = INPUT #7 8 = INPUT #8
o OBLK Black screen selection. Rd/Wr 0 1 1 = black screen
G TAKE Transition status. Rd 0 1
1 = transition in process (automatic reset at
the end of the effect transition).
Z FRZ FREEZE. Rd/Wr 0 1 0 = inactive 1 = active.
* tE EFFO Effect selection. Rd/Wr 0 2 0 = CUT 1 = FADE 2 = TITLE
INPUT COMMANDS
PC PCH Input selection for adjustment. Rd/Wr 0 8
0 = All inputs 1 = INPUT #1
2 = INPUT #2 3 = INPUT #3
4 = INPUT #4 5 = INPUT #5
6 = INPUT #6 7 = INPUT #7
8 = INPUT #8
PE PEN Input disabling (according to PCH). Rd/Wr 0 1 0 = Input disable 1 = Input enable
PL PLD H sync load selection (according PCH) Rd/Wr 0 1 0 = Hi-Z load 1 = 75Ω load
PR PRGB
Input signal type selection. (according
to PCH).
Rd/Wr 0 9
0 = SDTV Composite 1 = SDTV S.VIDEO
2 = SDTV YUV
3 = SDTV RGBS TTL
4 = SDTV RGsB 5 = SDTV RGBS ana.
6 = Computer (SOG) 7 = Computer H&V/C
8 = HDTV
9 = Audio only
PI PSTD
Input standard selection (according to
PCH).
Rd/Wr 0 6
0 = NTSC / PAL / SECAM
1 = NTSC
2 = PAL
3 = NTSC 4.43 60Hz 4 = PAL 4.43 60 Hz
5 = SECAM
6 = Black & White
PP PPRC VCR mode (according to PCH). Rd/Wr 0 1 0 = OFF 1 = ON
OUTPUT COMMANDS
If fast switching =
internal rate input # X
F OFMT Output format selection. Rd/Wr 0 12
0 = VGA 60 Hz 0 = 640x480L
1 = SVGA 60 Hz 1 = 800x600L
2 = XGA 60 Hz 2 = 1024x768L
3 = SXGA 60 Hz 3 = 1280x1024L
4 = SXGA+ 60Hz 4 = 1400 x1050 L.
5 = VGA 75 Hz 5 = 640x480L
6 = SVGA 75 Hz 6 = 800x600L
7 = XGA 75 Hz 7 = 1024x768L
8 = SXGA 75 Hz 8 = 1280x1024L
9 = D-ILA 4/3 9 = 1365x1024L
10 = D-ILA 16/9 10 = 1365x768L
11 = HDTV 480p 11 = HDTV 480p
12 = HDTV 720p 12 = HDTV 720p.
fm OSYN Output sync selection. Rd/Wr 0 2
0 = H &V 1 = Composite
2 = SOG (Sync On Green).
fs SCRN Type of screen selection Rd/Wr 0 1 0 = screen 4/3 1 = screen 16/9
p OPAT Test pattern. Rd/Wr 0 2
0 = no pattern 1 = centering
2 = color bar
mH MHPO Centering pattern: horizontal position. Rd/Wr 0 255
mV MVPO Centering pattern: vertical position. Rd/Wr 0 63
mW MHSZ Centering pattern: horizontal size. Rd/Wr 0 255
mS MVSZ Centering pattern: vertical size. Rd/Wr 0 63
NOTE: * = command available on the OCTO-FADE ™ & OCTO-FX ™ only. Rd = Read only command.
** = command available on the OCTO-LOGO ™ & OCTO-FX ™ only. Rd/Wr = Read and write command.
