26
INSECT ALERT
Your Performer Grill, as well as any outdoor gas appliance, is a target for spiders and
insects. They can nest in the venturi section (1) of the burner tube causing gas to flow
back out of the air shutter.
This could result in a fire in and around the burner tube under the bowl panel. It can
cause serious damage to your barbecue, rendering it unsafe to operate.
We strongly recommend that you inspect and clean the burner tube at least once a year,
or if any of the following symptoms occur:
A) The smell of gas in conjunction with the burner flames appearing very yellow and
lazy.
B) Burner makes popping noises.
m DANGER
Failure to correct these symptoms may result in a fire which
can cause serious bodily injury or death and cause damage to
property.
MAINTENANCE
1
3
2
5
4
6
INSPECTING AND CLEANING THE BURNER
A) Turn gas to OFF.
B) Remove the CHARBIN storage container.
C) Remove orifice clip (2) and hose fitting (3) from the burner tube.
D) Look inside the burner with a flashlight.
E) Clean the inside of the burner with the wire matchstick holder (mounted behind the
WEBER logo plate).
Use the wire to clean the air shutter area, the venturi section, and the burner slots
(4) on the inside of the bowl. Be careful when inserting the burner cleaning tool not
to damage the igniter electrode (5).
F) Recheck with flashlight to see that there are no obstructions.
G) If necessary, surface of hose fitting can be cleaned with a brass wire brush. The
orifice (6) can be cleaned with a small pin.
m CAUTION: Do not enlarge the orifice when cleaning.
H) Reassemble by reversing steps B and C.
