Multi-Contact MA030 - Manuel

Advanced Contact Technology
www.multi-contact.com 1 / 8
FSA20...
MA030 (fr_en)
Notice de montage MA030 (fr_en)
Assembly instructions
Fourche étroite
FSA20K..., FSA20A... à confectionner soi-même Flact contact clamp
FSA20K..., FSA20A... for self assembly
Contenu
Consignes de sécurité ................................................................2
Outillage nécessaire ..................................................................3
Confection du câble ..................................................................4
Démontage ................................................................................7
Notes .........................................................................................8 Content
Safety Instructions ......................................................................2
Tools required ............................................................................3
Wire assembly ...........................................................................4
Dismantling ...............................................................................7
Notes .........................................................................................8
Vis PT (pour thermoplast)
PT-Screw (for thermoplast)
KA3,5x35
Goupille fendue
Heavy type dowel pin
DIN1481 Ø4x32
Gaine thermorétractable (préencollée)
Shrink sleeve (with adhesive)
Fыt а sertir
Crimp sleeve
A-P...
Isolation
Insulation
Demi-coques d‘isolation
Insulation shells
