Polaris 2006 Victory Vegas - Manuel (Page 128)

126
MAINTENANCE
Check Engine Compression
An accurate periodic engine compression check documents engine wear and condition. For engine compression
check procedures and special tools required, see the VICTORY Service Manual or contact an authorized VICTORY
dealer.
Check Exhaust System
Check the exhaust system for stains from leaking exhaust gasses. Replace exhaust gaskets if necessary (see the
VICTORY Service Manual or an authorized VICTORY dealer). Check all exhaust system fasteners.
1. Tighten exhaust header flange nuts.
Torque: 12 ft-lbs (16 Nm)
2. Tighten muffler clamps.
Torque: 31 ft-lbs (42 Nm)
3. Tighten muffler mounting bolts.
Torque: 18 ft-lbs (24.5 Nm)
4. Tighten muffler bracket nut.
Torque: 35 ft-lbs (47.5 Nm)
1. Header Flange Nut
2. Muffler Clamp 3. Muffler Mounting Screw
4. Muffler Bracket Nut
1
2 4
2
1
3
3
