110
MAINTENANCE
Clutch
Lubricate Clutch Lever
1. Remove right side cover.
2. Slide the rubber cover off the cable adjuster, and loosen the adjuster lock
nut (see page 111.)
3. Turn the cable adjuster all the way in to provide maximum lever free
play.
4. Remove clutch lever pivot nut (1), plate (2) and pivot screw (3). Use a
4mm hexagonal socket to remove the screw.
5. Disconnect the clutch cable from the clutch lever.
6. Remove any old grease and dirt from the clutch lever and lever housing.
7. Lubricate the clutch lever and lever pivot screw with VICTORY All
Purpose Grease or equivalent.
8. Reconnect the clutch cable and reinstall the lever and lever pivot screw.
9. Torque pivot screw to 60 in.-lbs. (7 Nm)
10. Install plate and nut.
11. Hold pivot screw and torque nut to 40 in-lbs (5 Nm)
12. Adjust clutch freeplay (page111)
1
2
3
AP
