Polaris 2006 Victory Vegas - Manuel (Page 109)

A
Fast Idle
Position
Fast Idle
Lever
B
107
MAINTENANCE
Fast Idle Lever and Cable
1. Move the fast idle lever. It should move smoothly from
its rest position to its completely open position and back
again. Measure fast idle lever free-play (A), which is
the amount of lever movement from the rest position to
the point of cable resistance.
Specification: 3-6mm, 1/8-1/4 in.
Fast Idle Lever Freeplay Adjustment
1. If adjustment is necessary, remove seat (page 127) and
fuel tank (page 105).
2. Loosen the fast idle cable adjuster lock nut (B).
3. Turn the cable adjuster in or out until freeplay at the lever
is 1/8-1/4 inch (3-6 mm).
4 Tighten the adjuster lock nut securely and reinstall the fuel
tank and operator’s seat.
5. Start the engine and let it idle with transmission in
NEUTRAL.
6. Turn the handlebars from full right to full left. If engine
RPM increases when bars are turned, re-check throttle
cable and fast idle cable adjustments, cable condition, and
routing. If problem persists contact your VICTORY dealer.
