© 2010 Baja, Inc. All Rights Reserved. 7 — English
FEATURES
Engine stop button — Press and hold the engine stop but-
ton to turn the engine off.
Front brake lever — The front brake can be applied by
squeezing the front brake lever.
Fuel valve — This vehicle has one manually operated fuel
valve featuring 3 positions.
In the ON position, fuel is allowed to flow into the carburetor
when the engine is running or being started.
In the OFF position, fuel is shut off from the carburetor. The
fuel valve needs to be placed in this position when the dirt
bike is not in use.
If the fuel level in the tank becomes too low for the engine to
run while in the ON position, turn the fuel valve to RESERVE.
This will allow the engine to begin using the reserve fuel
supply. There is approximately 1 liter of fuel left in the tank
in the reserve position. Refuel as soon as possible and then
place the fuel valve back in the ON position.
Fuel tank cap — To open the fuel tank cap, turn the cap
counterclockwise. To close, turn the cap clockwise and
tighten it securely.
Ignition switch (if equipped) — The ignition switch is used
for starting and stopping the engine.
Kick start lever — Depress the kick start lever to start the
engine.
Manual choke lever — When engine is cold, place the choke
lever in the ON position. When engine has warmed up, move
lever back to the OFF position.
Rear brake pedal — The rear brake can be applied by de-
pressing the brake pedal.
Throttle grip — Controls engine and dirt bike speed. Ro-
tate the throttle grip backward (toward operator) to increase
engine and dirt bike speed. Rotate the throttle grip forward
(away from operator) to decrease engine and dirt bike speed.
FUEL
VALVE
FUEL TANK
CAP
FRONT
WHEEL
REAR
WHEEL
GEAR SHIFT
PEDAL
SIDE
STAND
