© 2010 Baja, Inc. All Rights Reserved. 11 — English
OPERATION
 Carefully pour fuel into the tank until the level reaches
approximately 2 in. below the top of the fuel tank opening.
Avoid spillage.
 Replace fuel tank cap and turn clockwise to secure.
 If it came loose during refueling, replace the vent tube in
the fuel tank cap. Make sure the other end of the tube is
still installed in the number plate.
WARNING:
Check for fuel leaks. A leaking fuel cap is a fire hazard and
must be replaced with an original manufacturer’s replace-
ment cap immediately. If you find any leaks, correct the
problem before using the product. Failure to do so could
result in a fire that could cause serous personal injury.
WARNING:
Overfilling the fuel tank could be hazardous. If you overfill
the fuel tank, fuel may overflow when it expands due to
heat from engine or sun. Spilled fuel could catch fire or
explode, resulting in serious personal injury.
WARNING:
Failure to complete the pre-ride inspection and verify
proper performance of the dirt bike before riding can result
in serious personal injury.
PRE-RIDE INSPECTION
ITEM TO
CHECK ITEM MUST PERFORM AS FOLLOWS:
Steering Smoothness; no restriction of movement; no
play or looseness.
Brakes Proper brake lever free play; enough brake
force.
Tires Proper air pressure; enough tread depth; no
cracks, rips, or other damages.
Fuel Enough fuel for the intended trip.
Fuel cap No damage to fuel tank or cap; fuel tank cap
closed securely.
Engine
stop button
Proper operation of button. Start engine,
then press stop button. Engine should stop.
Engine
lubricant
Proper level; check lubricant by inspecting
engine oil dip stick. The engine lubricant
should be between the minimum and maxi-
mum lines.
Throttle Proper free play of throttle grip; smooth re-
sponse; quick return to idle position.
General
condition
Bolts and nuts are tight; no rattle from any
parts of the engine when running; no visible
evidence of damage including frame cracks.
STARTING THE ENGINE
 If equipped with an ignition key, insert key into ignition
switch and turn to ON position.
 Make sure transmission is in neutral.
 Turn the fuel valve to the ON position.
 Place the choke lever in the ON position.
 Start the engine using the ignition switch (if equipped) or
the kick start lever.
 Allow engine to warm, then move the choke lever to the
OFF position.
WARNING:
Always open the throttle gradually when you want to ac-
celerate. Opening the throttle suddenly could cause the
front wheel to leave the ground and cause loss of control
of the dirt bike causing serious personal injury.
WARNING:
Always keep both hands on the handlebars and both
feet on the foot rests of your dirt bike during operation.
Removing even one hand or foot can reduce your ability
to control the dirt bike or could cause you to lose your
balance and fall off the dirt bike. If you remove a foot from
the foot rest, you may come in contact with the dirt bike,
ground, obstacles, etc., which could cause an accident
and result in serious personal injury.
STOPPING THE ENGINE
 Rotate the throttle grip forward (away from you) to slow
down the engine.
 Press and hold the engine stop button to turn the engine
off.
 Turn the fuel valve to the OFF position.
 If equipped with an ignition key, turn key to OFF position,
then remove key from switch.
