P.09
Washer Dimensions
INSTALLATION REQUIREMENTS
23"
(585 mm)
The dimensions shown are for the recommended spacing. Custom dercounter installation
23 "
( 595 mm)
1"
(25 mm)
1"
(25 mm)
2" (50 mm)
" min.
(850 mm)
1 / 2
1 / 2
1 /
2
1 / 2
41 "
(103 5 mm)
23 "
(595 mm)
33
33
"
(850mm)
1.A120v.60Hz,AConly,15-or 20amp,fused electrical supply is required. A time-delay fuse
or circuit serving only this appliance be provided .
2.This washer is equipped with a power supply cord having a 3 prong grounding plug.
3.To minimize possible shock hazard ,the cord must be plugged into a mating,3 prong,
grounding type outlet ,grounded in accordance with accordance with local codes and
ordinances. If a mating outlet is not available ,it is the personal responsibility and
obligation of the customerto have the properly grounded outlet installed by a qualified
electrician.
4.If codes permit and a separate ground wire is used ,it is recommended that a qualified
electrician determine that the ground path is adequate.
5.Do not ground to a gas pipe .
6.Check with a qualified electrician if you are not sure the washer is properly grounded.
7.Do not have a fuse in the neutral or ground circuit.
Unpacking the washing machine
Unpack your washing machine and check if there is any damage during the transportation.
Also make sure that all the items (as shown in Page 5) in the attached bag arereceived.
If there is any damage to the washing machine during the transportation, or anyitem is
missing, please contact the local dealer immediately.
