Curtis RWD200 - Manuel (Page 17)

P.17
OPERATING INSTRUCTIONS
View of Control Panel
1. Power :Pressing [Power] to start the display. If the display is active, press to put the
washer into standby mode .If the washer is paused and the cycle is not restarted within
10 minutes,the current wash cycle will be cancelled.
2. Start/Pause :Press to start a wash cycle. If the washer is running, pressing it once will
pause the washer. Press again to restart the wash cycle.
NOTE:If the washer is paused and the cycle is not restarted within 10 minutes, the current
wash cycle will be cancelled.
3. Change Cycles and Options:Not all Options are available with all Cycles.
Cycles and Options can be changed anytime before Start/Pause is pressed.
4. To cancel a cycle.
a Press [Power] for 3 seconds to stop the cycle ,the door is unlock .Then change the cycle
b Press Start/Pause once and select the desired option.
5. To drain the washer manually.
a.Press Power for approximately 3 seconds.
b.Select Spin.
d.Press and hold START/PAUSE.
e.When the spin is complete, the door unlocks. Items can be removed from the washer.
6. Wash cycle.
Cotton/Normal: You can select this procedure to wash the daily washable clothes. The
washing period is quite long with quite strong washing intensive. It is recommended to
wash the daily cotton articles, for example: bed sheets, quilt covers, pillowcases, gowns,
underwear etc.
Bulky/ Large:To increase the washing effects, main additional washing time is increased.
Except single quick, wash, drain and spin procedures, the other procedures can select
Cotton intensive function. It is recommended to wash the clothes for babies or worn by
the persons with allergic skin.
Sport: In this cycle, active enzyme can help wash the clothes which are not easily cleaned
in the way of 40℃ prewash and main wash.
Delicate: You can choose this procedure to wash silk clothes.
Hand Wash/ Wool: You can select this procedure to wash the wool textiles labeled with
Start/
Pause
Hold 3 Sec.
Add Garment
Cotton/Normal
Baby Wear
Refresh
Sport
Delicate
Cotton/Normal
Bulky/Large
Hand Wash
/Wool
Rinse&Spin
Spin
Dry
Power
Speed Wash
Sanitary
∞
Drying
Extra Rinse
My Cycle
Pre-wash Temp. Delay Spin Speed Soil Level
Child Lock
F
Notes:
- The Control panel line chart is for reference only,Please refer to real product as standard.
- The Control panel could be changed without written notice. Please visit the website of
Washing Machine or call up the service line for consultation.
