9
THE REFILLABLE PLASTIC KEG
The WHITE adaptor for 6L kegs and plastic kegs is compatible with
the plastic keg.
1. Remove the cap from the plastic keg and fill with the beverage of your choice.
2. To avoid blockages and possible damage to the tap mechanism:
a) Do not fill with milk or any liquid containing milk.
b) Do not fill with any thick or sticky liquids.
c) Do not fill with any liquids containing fruit flesh or other particles.
d) Do not fill above the ‘maximum’ level marked around the body of the keg.
3. When filling the keg with a carbonated beverage such as beer it is preferable to use the
entire keg in one go. Otherwise, the beverage is likely to go flat.
4. Locate the WHITE adaptor and the white rigid tube. Check that the connection valves
on the tubes are disconnected from each end of the adaptor. If this is not the case, remove
them by pressing the metal tab.
5. Insert the large neck of the white rigid tube into the pocket under the WHITE adaptor.
6. Insert the WHITE adaptor and the white rigid tube into the plastic keg and press the centre
of the WHITE adaptor to firmly clip the adaptor onto the keg.
7. Next, install the outlet tube by lowering the handle of the tap and inserting the tube
into the opening located at the back. The tube must reach the outlet of the tap and
the clamp (black rectangle) must automatically lock to hold the tube in place.
Check that the clamp is correctly positioned in the designated space.
8. Connect the outlet tube with the WHITE adaptor to the ‘BEER OUT' nozzle.
9. Attach the air or CO2 inlet tube to one of the metal ‘air’ or ‘CO2’ connectors located in
front of the lid hinge.
Should you wish to use the air pump on the machine:
- Locate the flexible air or CO2 inlet tube.
N.B.: The flexible air or CO2 inlet tube is equipped with a ‘backstop valve’. The red arrow
on the valve, indicating the direction of connection, must be directed towards the WHITE
adaptor. In the event of poor connection, the beverage will leak into the pump, resulting
in the machine having to be returned to our technical department for examination and
repair at your expense.
- Place the flexible tube over the metal ‘AIR’ nozzle and fasten the retaining spring over the
top of it to ensure the connection is perfectly airtight.
- Connect the flexible tube to the ‘AIR IN’ nozzle of the WHITE adaptor. The red arrow on
the flexible tube must be positioned to face the WHITE adaptor.
- Move the pump slide to AIR ON (slide to the top). The pump will send air through the keg
to ensure the correct level of pressure.
