6
FITTING A 5L PRESSURISED BEER KEG
The WHITE adaptor is compatible with 5L pressurised kegs.
1. Before putting the keg in the machine, connect the WHITE adaptor to the outlet tube
by locking the outlet tube valve onto the WHITE adaptor.
2. Open the lid of the machine using the lever located in the middle of the lid.
Next, install the outlet tube connected to the WHITE adaptor by lowering the handle
of the tap and inserting the tube into the opening located at the back. The tube must
reach the outlet of the tap and the clamp (black rectangle) must automatically lock to
hold the tube in place.
Check that the clamp is correctly positioned in the designated space.
If the tube protrudes past the tap, simply cut the overhanging tube to the required length.
3. Put the keg in the appliance and firmly fasten the WHITE adaptor to the keg.
4. The beverage outlet tube must form a continuation of the handle so as not to interfere
with the closing of the lid. To ensure that this is the case, place the tube in the white plastic
collar located at the top of the vat. The collar will now hold the outlet tube onto the shaft
of the tap, thus preventing it from being crushed when the lid is closed.
5. Move the pump slide (located under the lid) to AIR OFF (slide to the bottom). The
pump does not need to be sending out air as the keg is already pressurised.
The air pump is not required for pressurised kegs as they provide their own pressure
for pouring.
6. Rinse and wipe up any traces of spillage thoroughly.
7. Close the lid of the machine.
8. Plug the connector into the machine’s power socket and press the switch to the rear of
the appliance.
9. Adjust the temperature.
The temperature display on the front of the machine will indicate the temperature
inside the machine on the outer wall of the keg.
The cooling temperature can be adjusted by turning the temperature regulation
button clockwise to reduce (-) or anti-clockwise to increase (+) the temperature.
You will then need to allow some time for the content of the keg to reach the temperature
indicated on the display, which is why it is recommended that you perform this operation
before serving the first beverage from the keg.
5L UNPRESSURISED KEGS
The YELLOW adaptor is compatible with 5L unpressurised kegs.
1. Check that there is a translucent gasket (seal) on the rigid yellow tube.
2. Screw the rigid yellow tube onto the YELLOW adaptor.
3. Pass the flexible black ring provided around the rigid tube and bring the ring up from
