14
1. Flick the switch at the rear of the machine to 0.
2. Unplug the appliance.
3. Wipe the outer surface using a damp cloth and a few drops of washing-up liquid if
necessary.
4. Clean the front of the tap using a damp cloth.
5. Clean the cooling chamber of the machine using a damp cloth or sponge. Never fill the
cooling chamber as this will damage the appliance and never use aggressive detergents.
6. Clean the outlet tube, removing it from the tap by lowering the handle and pulling gently.
Rinse the outlet tube in warm soapy water, rinse and dry.
7. Clean the connection valves and tubes. IMPORTANT: all accessories must be
disassembled and cleaned with the utmost care. Any beer, wine or fruit juice residue may
ferment in the connections and result in beverage contamination.
a) Squeeze a spring clamp to loosen it.
b) Slide it along the tube, away from the connection valve.
c) Separate the connection valve from the tube.
d) Wash removable parts in warm soapy water, and squeeze and roll the ends of the
tubes between two fingers to clean inside them, rinse and dry.
e) Reconnect the tube and the connection valve using spring clamps.
f ) Squeeze a spring clamp to loosen it.
g) Slide it along the tube, over the end of the valve.
8 Do not put any parts of the appliance in the dishwasher.
9 Do not immerse the appliance in water or any other liquid.
10 Do not use aggressive detergents such as vinegar, acid products, solvents or spirits to
clean your machine.
N.B.: To clean the WHITE adaptor for 6L kegs and plastic kegs properly connect the inlet
and outlet tubes to the adaptor. Under the tap, flush water through the end of each tube
in turn to thoroughly rinse the inside of the adaptor. The water should flow freely out of
the holes in the middle of the adaptor.
To avoid environmental and health problems due to hazardous substances
in electrical and electronic goods, appliances marked with this symbol
mustn’t be disposed of with unsorted municipal waste, but recovered,
reused, or recycled.
