11
2 Attach the WHITE adaptor to the keg before putting the keg in the machine by
pressing the centre of the adaptor and pushing the adaptor on to the top of the keg
as firmly as possible.
Check that the adaptor is firmly connected to the keg before continuing.
3 Install the outlet tube by lowering the handle of the tap and inserting the tube into
the opening located at the back. The tube must reach the outlet of the tap and the
clamp (black rectangle) must automatically lock to hold the tube in place.
Check that the clamp is correctly positioned in the designated space.
4 Fasten the outlet tube onto the end of one of the connection valves.
5 Position the connection valve connected to the outlet tube onto the ‘BEER OUT’ nozzle
of the WHITE adaptor.
6 Attach the air or CO2 inlet tube to one of the metal ‘air’ or ‘CO2’ connectors located in front
of the lid hinge.
Should you wish to use the air pump on the machine:
- Locate the flexible air or CO2 inlet tube.
N.B.: The flexible air or CO2 inlet tube is equipped with a ‘backstop valve’. The red arrow
on the valve, indicating the direction of connection, must be directed towards the WHITE
adaptor. In the event of poor connection, the beverage will leak into the pump, resulting
in the machine having to be returned to our technical department for examination and
repair at your expense.
- Place the flexible tube over the metal ‘AIR’ nozzle and fasten the retaining spring over the
top of it to ensure the connection is perfectly airtight.
- Connect the flexible tube to the ‘AIR IN’ nozzle of the WHITE adaptor. The red arrow on
the flexible tube must be positioned to face the WHITE adaptor.
- Move the pump slide to AIR ON (slide to the top). The pump will send air through the keg
to ensure the correct level of pressure.
Should you wish to use the system with a CO2 cartridge:
- Locate the flexible air or CO2 inlet tube.
N.B.: The flexible air or CO2 inlet tube is equipped with a ‘backstop valve’. The red arrow
on the valve, indicating the direction of connection, must be directed towards the WHITE
adaptor. In the event of poor connection, the beverage will leak into the pump, resulting
in the machine having to be returned to our technical department for examination and
repair at your expense.
- Place the flexible tube over the metal ‘CO2’ nozzle and fasten the retaining spring over
the top of it to ensure the connection is perfectly airtight.
- Connect the flexible tube to the ‘AIR IN’ nozzle of the WHITE adaptor. The red arrow on
the flexible tube must be positioned to face the WHITE adaptor.
- Move the pump slide to AIR OFF (slide to the bottom). The pump does not need to be
sending out air as the pressure will be provided by the cartridge.
For information on attaching the CO2 cartridge see the paragraph on ‘Positioning and
connecting the CO2 cartridge’.
