12
7. Check that the tubes are not bent before closing the lid of the machine. If this is the case,
gently rotate the keg to undo any kinks in the tubes. The beverage outlet tube must form
a continuation of the handle so as not to interfere with the closing of the lid. To ensure
that this is the case, place the tube in the white plastic collar located at the top of the
vat. The collar will now hold the outlet tube onto the shaft of the tap, thus preventing
it from being crushed when the lid is closed.
8. Rinse and wipe up any traces of spillage thoroughly.
9. Close the lid of the machine.
10. Plug the connector into the machine’s power socket and press the switch to the rear
of the appliance.
11. Adjust the temperature.
The temperature display on the front of the machine will indicate the temperature
inside the machine on the outer wall of the keg.
The cooling temperature can be adjusted by turning the temperature regulation
button clockwise to reduce (-) or anti-clockwise to increase (+) the temperature.
You will then need to allow some time for the content of the keg to reach the temperature
indicated on the display, which is why it is recommended that you perform this operation
before serving the first beverage from the keg.
If the keg is empty
If you are only getting froth or air out of the tap this will generally mean that the keg is
empty.
You may disconnect a partially-used keg but this is not advisable as it can be a very messy
task.
Replacing a keg
1. Flick the switch at the rear of the machine to 0.
2. Place a glass under the tap and ensure that there is no more liquid coming from it.
3. Open the lid by raising the lever.
To remove the WHITE 5L adaptor from a pressurised keg:
- Squeeze the sides of the nozzle, taking care not to damage the attachments.
- Lift the adaptor from the keg and hold the adaptor above the level of the tap.
- Pull the handle of the tap fully forwards (45°) to empty the tap and the tube.
- Keep the handle of the tap in the forwards position and remove the outlet tube positioned
in the tap to the rear.
- Remove the keg from the appliance by lifting it out of the machine.
To remove the YELLOW adaptor from a pressurised keg:
- If you are using the air pump, move the pump slide to AIR OFF (slide to the bottom).
- If you are using the CO2 cartridge system, close the CO2 inlet by turning the tap on the
pressure gauge.
