31 - Solving Operational Problems
Before calling for service, check the following to avoid unnecessary service charges.
Oven Problem Problem Solving Steps
F03 or F04 Error appears in the
display window. A problem with latch mechanism occurred. Remove power and turn it back on again after
a few seconds. The oven should run a latch auto–test. If condition persists, note the code
number and call an authorized service.
Other F__ Error appears in the
display window. Remove power and turn it back on again after a few seconds. If condition persists, note the
code number and call an authorized service.
The oven display stays OFF Turn off power at the main power supply (fuse or breaker box). Turn breaker back on.
If condition persists, call an authorized service center.
Cooling fan continues to run after
oven is turned off The fan turns off automatically when the electronic components have cooled sufficiently.
Oven door is locked and will not
release, even after cooling Turn the oven off at the circuit breaker and wait a few seconds. Turn breaker back on.
The oven should reset itself and will be operable.
Oven is not heating Check the circuit breaker or fuse box to your house. Make sure there is proper electrical
power to the oven. Make sure the oven temperature has been selected.
Oven is not cooking evenly Check oven calibration. Adjust calibration if necessary (see To Set Temperature, Page
14). Refer to cook charts for recommended rack position. Always reduce recipe
temperature by 25°F (15°C) when baking with Convention Bake mode.
Oven temperature is too hot or too
cold The oven thermostat needs adjustment. See Calibrating Oven Temperature, Page 14.
Oven light is not working properly Replace or reinsert the light bulb if loose or defective. See Page 41. Touching the bulb
with fingers may cause the bulb to burn out.
v Check for obstruction in oven door. Check to see if hinge is bent or door switch broken.
Cannot remove lens cover on light There may be a soil build-up around the lens cover. Wipe lens cover area with a clean dry
towel prior to attempting to remove the lens cover.
Oven will not Self-Clean properly Allow the oven to cool before running Self-Clean. Always wipe out loose soils or heavy spill-
over before running Self-Clean. If oven is badly soiled, set oven for a four-hour Self-Clean.
See Preparing the Oven to Self-Clean, Page 36.
Clock and timer are not working
properly Make sure there is proper electrical power to the oven. See the Clock and Timer sections
on Page 14.
Excessive moisture When using Bake mode, preheat the oven first. Convection Bake and Convection Roast will
eliminate any moisture in oven (this is one of the advantages of convection).
Porcelain chips When oven racks are removed and replaced, always tilt racks upward and do not force them
to avoid chipping the porcelain..
Is the control knob set to the
proper heat level? See “Setting the Control Knobs” section.
Service Data Record
For authorized service or parts information see
“Fulgor Warranty ..”.
The location of the serial tag on the product can be seen when
the oven door is opened. It is located on the left side, centered
vertically just inside the oven cavity. See Page 7. Now is a good
time to write this information in the space below provided. Keep
your invoice for warranty validation.
Service Data Record
Model Number _________________________________
Serial Number __________________________________
Date of Installation or Occupancy __________________
