9 - Instruction for Use
Instruction for initial switch-on
Once the range has been connected to the power supply for
the first time, the control automatically prepares for setting a
number of user settings, which remain stored in case of any
subsequent switch-on.
NOTE: Both at the first and subsequest connections to the
power supply, the door lock mechanism performs a calibration
run -
in this phase, always keep the door closed.
• Language
• Temperature&Weight
• Time
• Data
Refer to the USER SETTING paragraph for setting
instructions.
After making the user settings, the control moves automatically
to the “Standby” display page.
Oven Cavity Selection (Double Oven)
Once the appliance is switched ON two icons are showed on
the top left corner in order to inform the user which cavity is
selected and its condition.
• The RED color identifies the oven cavity ON (ACTIVE
FUNCTION).
• The WHITE color identifies the oven cavity ON (NOT ACTIVE
FUNCTION).
• The GRAY color identifies the oven cavity OFF.
• The frame identifies the Oven selection (SHOWN ON THE
DISPLAY).
EXAMPLE 1
UPPER oven:
GRAY icon - OFF (not selected)
LOWER oven: RED icon - ON (active / selected)
EXAMPLE 2
UPPER oven:
RED icon - ON (active / not selected)
LOWER oven: RED icon - ON (active / selected)
EXAMPLE 3
UPPER oven:
WHITE icon - ON (not active / selected)
LOWER oven: RED icon - ON (active / not selected)
EXAMPLE 4
UPPER oven:
WHITE icon - ON (not active / selected)
LOWER oven: GRAY icon - OFF (not selected)
NOTE: Press the [ON/OFF] knob to switch the oven ON
and press again to switch it OFF. The oven returns to
standby mode.
To select the Oven Cavity press the related [FUNCTION]
knob for 2 seconds.
If an oven cavity is OFF and selected while the other is ON,
an icon is showed on the display to advise that the cavity not
selected is activated.
