24 - Replacing an Oven Light
• Each oven is equipped with three halogen lights (per cavity)
located in the lateral walls of the oven.
• The lights are switched on when the door is opened or when
the oven is in a cooking cycle.
• The oven lights are not illuminated during SELF- CLEAN.
• Each light assembly consists of a removable lens, a light bulb
as well as a light socket housing that is fi xed in place. See
fi gure on this page.
• Light bulb replacement is considered to be a routine
maintenance item.
To Replace a Light Bulb
1. Read WARNING on this page.
2. Turn off power at the main power supply (fuse or breaker
box).
3. In ovens with lateral rack supports, remove them by
unscrewing the four screws.
4. Remove the lens between screw and glass using a screw
driver.
5. Remove the light bulb from its socket by pulling it.
6. Replace the bulb with a new one. Avoid touching the bulb
with fi ngers, as oils from hands can damage the bulb when
it becomes hot.
7. The bulb is halogen: use one with the same type checking
Voltage and Wattage.
8. Place the lens back on.
9. Replace the rack supports if provided is provided with the
oven model.
Turn power back on at the main power supply (fuse or breaker
box).
WARNING
• Make sure the oven and lights are cool and power to the
oven has been turned off before replacing the light bulb(s).
Failure to do so could result in electrical shock or burns.
• The lenses must be in place when using the oven.
• The lenses serve to protect the light bulb from breaking.
• The lenses are made of glass. Handle carefully to avoid
breakage. Broken glass could cause an injury.
OVEN LIGHT
