EN
32
20 - Setting The Self Cleaning Mode
To Set the Self-Clean Mode
1. Press the ON/OFF key (select the compartment to be cleaned
in case of double oven).
2. A message appears on the screen to remove all objects or
accessories from the compartment.
3. Press the START key to start door lock and cleaning cycle.
4. The clean time is displayed automatically, its standard value
is 3 hours.
11:00 am
SELF CLEAN
END
START
4:30 pm
1:30 pm
Start
STOP
5. At the end of the programmed cleaning time, the oven will
automatically turn off.
• To stop the cleaning mode at any moment, press
ON/OFF
key.
• The Self Cleaning cycle cannot be selected if the door is
open.
• If the door is in the open position when the function has
already been selected and the START key is pressed the
latch doesn’t move, the “PADLOCK” icon will flash until
the door will be closed and the lock motor stops. When
the “CLOSED PADLOCK” it is displayed, the door cannot
be opened.
• Check that the door has been locked, if door does not
lock, press ON/OFF key and do not start self-clean;
phone for service
• Do not attempt to open the door while the cleaning cycle
is running and the door is locked.
To Change the Cleaning Time
1. To change the setting from 3 hours, select either 2 hours for
light soil or 4 hours for heavy soil immediately after starting.
2. To change the hours, touch the COOK TIME key (the hours
will flash), use or keys to change the value, then press
START to confirm the new value.
3. To select the minutes, touch the key (the minutes will
flash), use or keys to change the value, then press
START to confirm the new value.
To Delay the Start of Cleaning
1. Follow steps 1 through 3 above.
2. Touch the
STOP TIME key and verify that “STOP TIME”
appears on the display. The hours will begin flashing, use
or keys to change the value, then press START to confirm
the new value.
3. To select the minutes, touch the key (the minutes will flash),
use or keys to change the value, then press START to
confirm the new value.
11:00 am
SELF CLEAN
END
TIME
2:00 pm
03:00
STOP
TIME
8. When the delay time expires, self-cleaning will start.
9. At the end of the programmed cleaning time, the oven will
automatically turn off.
CAUTION
Keep in mind that the oven door will remain locked until it is
safe enough to open. The lock symbol will disappear from
the display when the door lock is released.
You will still need to exercise caution when the door lock is
released because the inside of the oven may still be hot.
After the self-clean cycle is complete the oven control monitoring
the internal temperature and the following messages will be
displayed:
• From the 460°C/860°F to 270°C/518°F= “End pyrolisis”
• From the 270°C/518°F to 50°C/122°F= “Wait to clean”
• From the 50°C/122°F to 25°C/77°F= “Remove residues”
(Press ON/OFF key to clear the message).
You may notice a powder ash residue in the bottom of the oven
after self-cleaning. This condition is normal. Use a damp cloth
or sponge to wipe up the residue after the oven cools down.
Self-cleaning Tips:
• If any soil remains in the oven after the self-clean cycle is
complete, you may repeat the cycle if you want.
• Self-clean the oven regularly to prevent excessive soil build-
up. Doing so will make the self-clean cycle work better and
reduce smoke and odors.
