Fulgor Milano 700 Series 24 Inch Single Convection Electric Wall Oven Use and Care Manual - Manuel (Page 33)

EN
31
20 - Oven Door
Automatic door locking during pyrolytic cycle
For safety reasons, the door is locked automatically as soon
as self-clean mode is selected (both standard, both eco clean).
The door is also unlocked automatically when the clean time
has expired but only after the temperature has fallen below the
safety threshold.
NOTE It is not possible to exclude the door locking device
during self-cleaning i.e. manually unlock the door since
the self-cleaning mode has the highest priority and
overrides all other selections.
The lock symbol ( ) on the display is:
ON When the door is fully locked
OFF When the door is fully unlocked
FLASHING When the latch mechanism is moving or is
waiting for a command by the electronic control.
(After self clean the symbol will flash until the
temperature will be safe and the door unlocked).
Removing the “FULL GLASS” panoramic door
WARNING
Make sure that:
• The oven is cool and power to the oven has been turned
off before removing the door. Failure to do so could result
in electrical shock or burns.
• The oven door is heavy and fragile. Use both hands to
remove the oven door. The door front is glass. Handle
care-fully to avoid breakage.
• Grasp only the sides of the oven door. Do not grasp the
handle as it may swing in your hand and cause damage
or injury.
• Failure to grasp the oven door firmly and properly could
result in personal injury or product damage.
Removing the oven door
The oven door can be removed quickly and easily. To do so,
proceed as follows:
• Open the door fully.
• Lift the two levers shown below.
• Close the door as far as the first stop (caused by the raised
levers).
• Lift the door upwards and outwards to remove it fromits
mountings.
To replace fit the door, fit the hinges in their mountings and
lower the two levers
How to remove the inner glass of the “FULL
GLASS” panoramic door
1. Wear protective gloves.
2. Place the door on a flat horizontal surface face down on a
soft cloth to avoid scratching the visible part.
3. Simultaneously press the keys of the two side covers,
removing the upper strip.
