6
Electronic Oven Controls
Control Display
The display will light up when first powered up or after a power
loss. When oven is not in use, the time of day is displayed.
Tones
Tones are audible signals, indicating the following:
One Tone
� Valid keypad press
� Oven is preheated (long tone)
� Function has been entered.
� Kitchen timer (long tone with a reminder tone every 60
seconds).
Three Tones
� Invalid keypad press
Four Tones
� End of cycle (with a reminder tone every 60 seconds).
Use the Options key to change the tone settings.
Options
Many features of the oven control can be adjusted to meet your
personal needs. These changes are made using the Options
keypad.
Use the Options keypad to scroll through the features that can be
changed. Each press of the Options keypad will advance the
display to the next setting. After selecting the feature to be
changed, the control will prompt you for the required input. Details
of all of the feature changes are explained in the following
sections.
Press OFF to exit Options.
Fahrenheit and Celsius
The temperature is preset to Fahrenheit but can be changed to
Celsius.
1. Press OPTIONS until “TEMP UNIT” is displayed.
2. The current setting will be displayed.
3. Press the “1” keypad to adjust the setting.
4. Press OFF to save the setting and display the time of day.
Audible Tones Disable
Turns off all tones, including the end of cycle tone and key press
tones.
1. Press OPTIONS until “SOUND” is displayed.
2. The current setting will be displayed.
3. Press the “1” keypad to adjust the setting.
4. Press OFF to save the setting and display the time of day.
Sound Volume
Sets the pitch of the tone to either high or low.
1. Press OPTIONS until “SOUND VOLUME” is displayed.
2. The current setting will be displayed.
3. Press the “1” keypad to adjust the setting.
4. Press OFF to save the setting and display the time of day.
End-of-Cycle Tone
Activates or turns off the tones that sound at the end of a cycle.
1. Press OPTIONS until “END TONE” is displayed.
2. The current setting will be displayed.
3. Press the “1” keypad to adjust the setting.
4. Press OFF to save the setting and display the time of day.
Keypress Tones
Activates or turns off the tones when a keypad is pressed.
1. Press OPTIONS until “KEYPRESS TONE” is displayed.
2. The current setting will be displayed.
3. Press the “1” keypad to adjust the setting.
4. Press OFF to save the setting and display the time of day.
Reminder Tones Disable
Turns off the short repeating tone that sounds every 1 minute after
the end-of-cycle tones.
1. Press OPTIONS until “REMINDER TONE” is displayed.
2. The current setting will be displayed.
3. Press the “1” keypad to adjust the setting.
4. Press OFF to save the setting and display the time of day.
12/24 Hour Clock
1. Press OPTIONS until “12/24 HOUR” is displayed.
2. The current setting will be displayed.
3. Press the “1” keypad to adjust the setting.
4. Press OFF to save the setting and display the time of day.
Demo Mode
IMPORTANT: This feature is intended for use on the sales floor
with 120 V power connection and permits the control features to
be demonstrated without heating elements or burners turning on.
If this feature is activated, the oven will not work.
1. Press OPTIONS until “DEMO MODE” is displayed.
2. The current setting will be displayed.
3. Press the “1” keypad to adjust the setting.
4. Press OFF to save the setting and display the time of day.
12-Hour Shutoff
The oven control is set to automatically shut off the oven 12 hours
after the oven initiates a cook or clean function. This will not
interfere with any timed or delay cook functions.
1. Press OPTIONS until “12 HR AUTO OFF” is displayed.
2. The current setting will be displayed.
3. Press the “1” keypad to adjust the setting.
4. Press OFF to save the setting and display the time of day.
Languages: Scrolling Display Text
Language options are English, Spanish, and French.
1. Press OPTIONS until “LANGUAGE” is displayed.
2. The current setting will be displayed.
3. Press the number keypads to adjust the setting.
4. Press OFF to save the setting and display the time of day.
Energy Save
The Energy Save mode puts the range into Sleep mode and
reduces energy consumption.
1. Press OPTIONS until “ENERGY SAVE” is displayed.
2. The current setting will be displayed.
3. Press the “1” keypad to adjust the setting.
4. Press OFF to save the setting and display the time of day.
Oven Temperature Offset Control
IMPORTANT: Do not use a thermometer to measure oven
temperature. Elements will cycle on and off as needed to provide
consistent temperature but may run slightly hot or cool at any
point in time due to this cycling. Most thermometers are slow to
react to temperature change and will not provide an accurate
reading due to this cycling.
The oven provides accurate temperatures; however, it may cook
faster or slower than your previous oven, so the temperature can
be adjusted to personalize it for your cooking needs. It can be
changed to Fahrenheit or Celsius.
To Adjust Oven Temperature:
1. Press OPTIONS until “TEMP CALIB” is displayed.
2. The current setting will be displayed. Press the “1” keypad to
toggle between the oven and the warming drawer.
3. Press START to select the choice displayed in Step 2. Wait 10
seconds for the display to change, or press START, and then
continue with Step 4.
