3 4
Accessories
Introduction
W arnings Specifications
Fine digital control
NTSC3.58
75W (Unbalance)
Model
Power adaptor
LED
PLED1960A-C
Display screen type Color active matrix LED display
Sound output(Max) 2 x 5W
0 C-40 C o o
Display Size 19”
Power Consumption (Max) 32W
1366X768
Display Screen Type
DC 12V 3A
Remarks:
The above listed specifications and data are subject to change without prior notice.
Please make sure the following items are included with your LED TV. If any items are
missing, contact your dealer.
Remote Control &
Batteries (AAAx 2)
DC Adapter
Owner’ s
Instructions
SPEAKER
REMOTE CONTROL SENSOR
Aim the remote control towards this
spot on the TV.
POWER INDICATOR
Green: In power on mode.
Red: In standby mode.
Toggles between all the available input
CH+/-
Press to change channels.
In the on-screen menu, use the CH +/-
buttons as up/down arrow buttons.
VOL+/-
Press to increase or decrease the volume.
In the on-screen menu, use the VOL +/-
buttons as left/right arrow buttons.
POWER
Press POWER button to toggle between
and standby mode. normal MENU
Press to see an on-screen menu of your
TV's features.
SOURCE
sources ( TV, AV, YPbPr, HDMI 1,
General Description
Overview of front and side panel
Warranty Card
Assembllng
Stand Process
Antenna: 2~69; Cable: 1~135 (Analog: 1-125,
Digital: 1-135)
NTSC System, ATSC System
W arnings Features
SERVICE PORT
E
4 5 6 7 8
HDMI 2,PC)
