页面 31, Instruction, Remote control key functions – Curtis LCDVD241FR Manuel d'utilisation
Page 31
11
(1) POWER button: Switches the set on from power on or off (Main power switch must be turned on).
(2) AUTO/ button: Press to pc source picture auto adjust;
Press in DVD source Load/ Eject DVD disk.
(3) MUTE button: Press to eliminate or restore the TV sound.
(4) P.MODE button:
Press to select preset picture mode
.
(5) S.MODE button:
Press to select
Sound mode button.
(6) NICAM button:
(7) INFO
button
:
Press to display current status,
TV channel,
input source.
(8) Numerical buttons:
Press number buttons for direct access TV channels.
(9)
10+/
LIST button: Direct input numerical button
for 2 digit or 3 digit program;
Press to display the channel list.
(10) button:
Press to return to previous channel
.
(11) MENU button: LCD menu selection.
(12) DVD SETUP / EXIT button: Displays the DVD SETUP Menu;
Exit the OSD menu (On-screen display).
(13) SOURCE button:
Press to display all possible input sources
(14) SLEEP button: Sets the sleep timer。
(15) " "button: When OSD menu is on, press this button
to move the selection focus up or change settings.
(16) " "button: When OSD menu is on, press this button
to move the selection focus down or change settings.
(17) " "button: When OSD menu is on, press this button
to move the selection focus left.
(18) " "button: When OSD menu is on, press this button
to move the selection focus right.
(19) " OK "button: Press the button to confirm the operation.
(20) CH- button: Changes the channels down.
(21) CH+ button: Changes the channels up.
(22) VOL- button: Adjusts the volume down.
(23) VOL+ button: Adjusts the volume up.
REMOTE CONTROL KEY FUNCTIONS
INSTRUCTION
10
REMOTE CONTROL KEY FUNCTIONS
INSTRUCTION
SUBTITLE
AUDIO
D.MENU
D.DISP
TITLE
ANGLE
INTRO
A
-
B
PROG
GOTO
SOURCE
10+
ZOOM
SIZE
REVEAL
SUBPAGE
INDEX
REPEAT
TEXT
HOLD
LANG
EPG
SLOW
STEP
LIST
DVD SETUP
INFO
NICAM
OK
19
22
23
20
21
SUBTITLE
AUDIO
D.MENU
D.DISP
TITLE
ANGLE
INTRO
A
-
B
PROG
GOTO
SOURCE
10+
ZOOM
SIZE
REVEAL
SUBPAGE
INDEX
REPEAT
TEXT
HOLD
LANG
EPG
SLOW
STEP
LIST
DVD SETUP
INFO
NICAM
OK
26
30
29
31
24
25
27
28
32
33
35
34
36
37
39
38
40
41
43
42
(24) FAV/ button: Switch between custom set"Favorite list";
Press to play or pause the disc under DVD mode.
(25) button:
(26) SLOW button:
(27) EPG/ STEP button: Press in DVD source Load/ Eject DVD disk;
Play or pause the disc playing.
(28) TEXT/ button:
(29) HOLD/ button:
(30) LANG/ AUDIO button:
Change the DVD audio mode: left, right, mono, stereo.
(31) SUBTITLE button: Press the button to select
different captions.
(32) INDEX/ button:
(33) SIZE/ button:
(34) REVEAL/ANGLE button:
Select different angle of DVD.
(35) SUBPAGE/ ZOOM button:
Zoom the disc playing.
(36)
D.MENU button: Display the DVD MENU.
(37)
TITLE: During a DVD disc playback,
press to go to title menu if the disc contains title.
(38)
D.DISP button:
Display the program information.
(39)
GOTO button: DVD start playing from the desired time.
Press time and enter time
.
The unit starts playing
from you selected.
(40)
PROG button: To select the DVD program playback.
(41)
INTRO button: It will achieve navigation
function when play VCD/CD disk.
While the disk is working, press INTRO button.
The screen will split to 9 small screen to play each clip
by 3 sec(Video Discs) or 15 sec(Audio Discs).
Press the Numeric button to activate corresponding
small screen directly.
- If started the disc menu, preview will not function.
- If the current track started over 15 sec, this function will start from next track.
- For CD type discs, the INTRO is displayed and the selection window will not appear.
(42)
REPEAT button: Repeat playback the DVD play;
(43)
A-B button: Press to AB playback the DVD play;
