5
ELECTRONIC OVEN CONTROL
This manual covers different models. The oven you have purchased may have some or all of the items listed. The locations and
appearances of the items shown here may not match those of your model.
The oven’s controls are accessed through its control panel.
NOTE: Due to the sensitivity of the control panel, we have provided special instructions for cleaning. See “General Cleaning” section for
cleaning instructions.
Single Oven Control Panel
Double Oven Control Panel
Control Panel
The control panel houses the control menu and function controls.
The control pads are very sensitive and require only a light press
to activate.
For more information about the individual controls, see their
respective sections in this manual.
Welcome Guide
This appears on your display the first time the oven is powered
up. The Welcome Guide allows you to set up your new oven.
After every selection, a single beep will sound.
1. Select language by pressing the quickset pad below the
desired language.
2. Press the left or right arrow keys until the desired unit
preference (°F/lb or °C/Kg) is highlighted, then touch the
quickset pad below OK.
3. Set the clock using the number keypad or left and right arrow
keys. Select the mode (am/pm/24h) by pressing the quickset
pad below the desired mode. Then press the quickset pad
below OK.
4. Press the quickset pad below OK again to confirm that setup
is completed.
Display
When the oven is in use (active mode), the display shows the
time, mode, oven temperature and timer, if set. If the timer is not
set, the Set Timer Option will also be displayed.
After 5 minutes of inactivity, the display will go into standby
(sleep) mode, and the backlight of the display will dim. When the
oven is in operation, the display will remain active.
During programming, the display shows menus and the
appropriate selections for the respective cooking function.
A. Touch panel
B. Oven controls
C. Arrow keys
D. Display
E. Number keypad
F. Kitchen timer on/off
G. Self clean
H. Cancel
I. Start
J. Control lock
(hold 3 sec. to lock)
K. Settings
L. Oven light
M. Clock
N. Quickset pads
A. Upper oven controls
B. Touch panel
C. Arrow keys
D. Display
E. Number keypad
F. Kitchen timer on/off
G. Self clean
H. Start
I. Upper cancel
J. Lower cancel
K. Control lock
(hold 3 sec. to lock)
L. Settings
M. Oven light
N. Clock
O. Quickset pads
P. Lower oven controls
A
B C C D E F G
H
I
J K L M N
A B C D C E F G H
I
J
K L M N O P
