14
WIRING DIAGRAM
SE119A
Gnd
Ground
Screw
M
S15
Switch Operation
L-1 Lamps 120 V 1.5 Ohms
L-2 Speed 1 120 V 1.5 Ohms
L-3 Speed 2 120 V 2.0 Ohms
2.5 Ohms 120 V Speed 3 L-4
0.9 ±10% A
110 Watts
27.5 ±10% Ohms
55.7 ±10% Ohms
Motor Characteristics
Power Supply 120 VAC
Frequency 60 Hz
Amperage
Wattage Rating
Motor Resistance
Red - Brown
Red - Black
Red - Gray 86.8 ±10% Ohms
W (Common)
BK (Line)
BK (Line)
Y (Lamp)
GY (Speed 3)
R (Speed 2)
BR (Speed 1)
Mechanical push buttons
4 buttons 3 speeds
Y
Y
W
BR
8uF
Y
W
Common
R
Speed 3 Speed 2 Speed 1
BR
W GY BK
N L
Red - White 117.7 ±10% Ohms
