2
Optional tools:
Parts supplied:
NOTE: All parts supplied for installation are in the washer
basket.
4" min
(102 mm)
Wood block
Adjustable or open end
wrenches 1 ⁄
2
" (13 mm) and
9 ⁄
16
" (14 mm)
Ruler or measuring tape
Level
Pliers that open to 1 9 ⁄
16
"
(39.5 mm)
Flashlight Bucket
Beaded tie strap Drain hose
INSTALLATION REQUIREMENTS
Tools and Parts
Gather required tools and parts before starting installation.
Tools needed:
Transport bolt hole
plugs (Quantity will vary,
depending on model.)
Alternative Inlet Hoses:
(may be required for some installations, not supplied
with washer)
n 8212656RP 10 ft (3.0 m) Inlet hose, Black EPDM (2 pack)
n 8212641RP 5 ft (1.5 m) Inlet hose, Black EPDM (2 pack)
n 8212546RP 4 ft (1.2 m) Inlet hose, Black EPDM (2 pack)
n 8212545RP 5 ft (1.5 m) Inlet hose, Red and Blue EPDM
(2 pack)
n 8212487RP 5 ft (1.5 m) Nylon braided inlet hose (2 pack)
n 8212638RP 6 ft (1.8 m) Nylon braided inlet hose, space
saving 90° elbow, hypro-blue steel couplings
(2 pack)
n 8212637RP 6 ft (1.8 m) Inlet hose, Black EPDM, space
saving 90° elbow, hypro-blue steel couplings
(2 pack)
Available Accessories:
An optional matching pedestal is available for your washer.
Please contact your retailer for ordering information, or see
the Assistance or Service page on the back of your Use and
Care Guide.
Alternative parts
(Not supplied with washer)
Your installation may require additional parts. To order, please
refer to toll-free numbers on the back page of your Use and
Care Guide.
If you have: You will need:
Laundry tub or Sump pump system
standpipe taller than (if not already available)
96" (2.4 m)
Overhead sewer Standard 20 gal. (76 L) 30" (762 mm)
tall drain tub or utility sink and sump
pump (available from local plumbing
suppliers)
1" (25 mm) standpipe 2" (51 mm) diameter to 1" (25 mm)
diameter Standpipe Adapter
Part Number 3363920
Connect Kit Part Number 285835
Floor drain system Siphon Break Part Number 285834;
additional Drain Hose,
Part Number 8318155; and Connector
Kit, Part Number 285835
Drain hose too short Extension Drain Hose
Part Number 285863
Water faucets beyond 2 longer water fill hoses;
reach of fill hoses 6 ft (1.8 m) Part Number 76314
10 ft (3.0 m) Part Number 350008
Drain hose form and hose
clamp
Inlet hoses (2) with
washers (4)
Parts needed: (Not supplied with washer)
