La Crosse Technology WS-9640-IT - Manuel (Page 7)

7
3. Using other electrical products such as headphones or speakers operating on the
same signal frequency (915MHz) may prevent correct signal transmission and
reception.
4. Neighbours using electrical devices operating on the 915MHz signal frequency can
also cause interference.
Note:
When the 915MHz signal is received correctly, do not re-open the battery cover of either the
transmitter or Weather station, as the batteries may spring free from the contacts and force
a false reset. Should this happen accidentally then reset all units (see Setting up above)
otherwise transmission problems may occur.
The transmission range is about 100 m from the transmitter to the Weather station (in open
space). However, this depends on the surrounding environment and interference levels. If
no reception is possible despite the observation of these factors, all system units have to be
reset (see Setting up).
MOUNTING
POSITIONING THE WEATHER STATION:
The Weather Station has been designed to be hung onto wall or free standing.
To wall mount
Choose a sheltered place. Avoid direct rain and sunshine. Before wall mounting, please
check that the outdoor temperature values can be received from the desired locations.
1. Fix a screw (not supplied) into the desired wall, leaving the head
extended out the by about 5mm.
2. Remove the stand from the Weather Station by pulling it away from
the base and hang the station onto the screw. Remember to
ensure that it locks into place before releasing.
Free standing
With the foldout stand, the weather station can be placed onto
any flat surface.
POSITIONING THE TEMPERATURE TRANSMITTER:
The Transmitter is supplied with a holder that may be
attached to a wall with the two screws supplied. The Transmitter
can also be position on a flat surface by securing the stand to the
bottom to the Transmitter.
To wall mount:
1. Secure the bracket onto a desired wall using the screws and plastic
anchors.
2. Clip the remote temperature transmitter onto the bracket.
Note:
Before permanently fixing the transmitter wall base, place all units in the
desired locations to check that the outdoor temperature reading is receivable. In event that
the signal is not received, relocate the transmitters or move them slightly as this may help
the signal reception.
CARE AND MAINTENANCE:
 Extreme temperatures, vibration and shock should be avoided as these may cause
damage to the unit and give inaccurate forecasts and readings.
 When cleaning the display and casings, use a soft damp cloth only. Do not use
solvents or scouring agents as they may mark the LCD and casings.
 Do not submerge the unit in water.
 Immediately remove all low powered batteries to avoid leakage and damage. Replace
only with new batteries of the recommended type.
 Do not make any repair attempts to the unit. Return them to their original point of
purchase for repair by a qualified engineer. Opening and tampering with the unit may
invalidate their guarantee.
 Do not expose the units to extreme and sudden temperature changes, this may lead to
rapid changes in forecasts and readings and thereby reduce their accuracy.
