3
BATTERY CHANGE:
It is recommended to replace the batteries in all units regularly to ensure optimum accuracy
of these units (Battery life see Specifications below).
Please participate in the preservation of the environment. Return used
batteries to an authorised depot.
FUNCTION KEYS:
Weather station:
The weather station has four easy to use function keys.
SET key (Manual Setting):
 Press to enter the set mode for the following functions: Time zone, Daylight saving
time ON/OFF, Manual time, Year, Month, Date, Weekday and °C/°F settings.
MIN/ MAX key
 To toggle between the maximum/ minimum outdoor temperature and maximum/
minimum indoor temperature data
 Press to reset at the maximum or minimum temperature records of the indoor and the
outdoor channel (will reset all records to current level)
 Press to exit the setting mode
+ key
 To make adjustment for various settings
 In normal display, press to toggle between the display of the calendar and second of
time in the time display of LCD
LOW TEMP ALERT key
 To activate / deactivate the low temperature alarm (alarm will be triggered once the
outdoor temperature has dropped to 4 C)
 To exit from the manual setting mode
LCD SCREEN AND SETTINGS:
*When the outdoor signal is successfully received by the Weather Station, this icon will be
switched on. (If not successful, the icon will not be shown in LCD) So user can easily see
whether the last reception was successful (icon on) or not (icon off). On the other hand, the
short blinking of the icon shows that a reception is currently taking place.
For better distinctness the LCD screen is split into 3 sections displaying the information for
time and indoor data, weather forecast, and outdoor data.
Section 1 - OUTDOOR TEMPERATURE
 Display the current outdoor temperature.
 By pressing the MIN/ MAX key, display the stored MIN/MAX outdoor temperature,
with simultaneous display of MIN/ MAX icon.
 A signal reception symbol will be shown indicating that outdoor temperature signal is
received.
Section 2 - INDOOR DATA AND WEATHER ICON (FEATURED BY WEATHER MAN)
 Display indoor temperature and indoor humidity
 The current temperature condition is displayed in form of one of eight icons, featured
by weather man, which change in appearance according to the current outdoor
temperature.
 Format of the weather man icons refers to the below clause "Weather man Icon"
SET key
MIN/MAX key
+ key
Low temp alert key
Indoor Temperature
Display "Calendar"
or "Second"
Time display
Weather man
icon
Receiver low
battery icon
Outdoor Temperature
Low temp
alert icon
Time reception icon
Indoor humidity %RH
Outdoor signal
reception icon*
Transmitter low
battery icon
Min / Max icon
LOW TEMP
ALERT
