TO INCREASE THE RUNNING BELT TENSION:
A. Place wrench on the left belt tension bolt. Turn the wrench clockwise 1/4 turn to draw the rear roller and increase the
belt tension.
B. Repeat STEP A for the right belt tension bolt. You must be sure to turn both bolts the same number of turns,
so the rear roller will stay square relative to the frame.
C. Repeat STEP A and STEP B until the slipping is eliminated.
D. Be careful not to tighten the running belt tension too much as you can create excessive pressure on the front
the front and rear roller bearings. An excessively tightened running belt may damage the roller bearings that would result in
bearing noise from the front and rear rollers.
TO DECREASE THE TENSION ON THE RUNNING BELT, TURN BOTH BOLTS COUNTER-CLOCKWISE THE SAME
NUMBER OF TURNS.
B). Observe whether the running belt is toward the right or left side of the deck.
a. If toward the left side of the deck
Using wrench, turn the left adjustment bolt clockwise 1/4 turn and the right adjustment bolt counterclockwise 1/4.
b. If toward the right side of the deck
Using wrench, turn the right adjustment bolt clockwise 1/4 turn and the left adjustment bolt counterclockwis 1/4.
c. If the belt is still not centered, repeats the above steps until the running belt is on center.
C). After the belt is centered, increase the speed to 16kph and verify that it is running smoothly. Repeat the
above steps if it is necessary.
If the above procedure is unsuccessful in resolving the off-center, you may need to increase the belt tension.
CENTERING THE RUNNING BELT
When you run, you may push off harder with one foot than with another. The severity of the deflection depends
on the amount of force that one foot exerts in the relation to the other. This deflection can cause the belt to
move off-center. This deflection is normal and the running belt will centre when no body is on the running belt.
If the running belt remains consistently off-center, you will need to centre the running belt manually.
5. TROUBLE SHOOTING
This treadmill is designed in a way that in the event of an electrical fault, the machine will turn off
automatically to prevent any injuries to the user and to prevent damage to the machine (i.e. motor).
When the treadmill behaves erratically, simply reset the treadmill by turning the power switch off, waiting
for 1 minute then turning the power button back on.
If, after you have reset the treadmill, it is still not running correctly, please run the self-checking analyse
(please refer to Self-Checking) to distinguish what type of error problem the machine is encountering.
5.1 Alarm signals
Before attempting any work on the treadmill, ensure that the power is off and the plug is removed
from the power point.
Do not use extension leads as it may lead to power decrease and failure.
