SPECIFICATIONS
Dimension (WxDxH) 35.8" x 31.2" x 69.9"
(91 x 79 x 178 cm)
Width with door open 90° 44.2" (112 cm)
Width with door open 135° 64.4" (164 cm)
Weight 379 lbs. (172 kg)
Power requirements 115 V ~ 60 Hz, 15A minimum requirement
Power cord length 66.9" (170 cm)
INSTALLATION
UNPACK
WARNING
Fire or Explosion Hazard
•
Do not puncture refrigerant tubing.
•
Follow handling instructions carefully.
•
Flammable refrigerant used.
•
Failure to do so can result in death, explosion or fire.
IMPORTANT: Remove ALL exterior and interior packing materials
including the foam packing between the exterior condenser and the
refrigerator cabinet.
DOOR REMOVAL
(ONLY IF NEEDED)
Measure the refrigerator to make sure it will fit through the doorway.
If the refrigerator cannot pass easily through the doorway, follow the
instructions to remove the two refrigerator compartment doors and the
front panels of the flex temperature and freezer drawers.
WARNING
Electrical Shock Hazard
•
Disconnect power before removing doors.
•
Reconnect ground wire before operating.
•
Failure to do so could result in death or electric shock.
