19
3) Use on central heating for versions mixed with fan in WINTER position.
a) Place the switch on the ON position, the indicator lights up.
b) Place the temperature knob on frost-free.
Turbo mode (see paragraph 2-3)
Repeat elements a) to d).
NB:The temperature adjustment of the device is made using the tap C (thermostatic or not).
4) Locking commands
It is possible to lock the knob or restrict its use, preventing untimely handling of the device (chil-
dren…).
1- Locking the knob:
a) Set the knob to the position required.
b) Using a small-size flat-blade screwdriver, pull the knob’s cap (1).
c) Detach pin P from its stand using a cutting tool.
d) Set pin P in the alignment of arrow B (2).
e) Refit the cap.
2- Limitation of the knob’s use range:
a) Using a small-size flat-blade screwdriver, pull the knob’s cap (1).
b) Remove the two P pins from their stand using a cutting tool.
c) Position the two P pins at each end of the operating range desired (3).
d) Refit the cap.
B
2 3
P
P 1
W
ARNING
- When filling a Mixed device, the hot water circuit must necessarily be used to allow the fluid to
expand in the heating circuit.
- This device is not intended for use by persons (including children) with physical, sensory or mental
disability, or by persons lacking experience or knowledge, unless they have received from a person
in charge of their safety adequate supervision or preliminary instructions on how to use the device.
- Prevent children from climbing on the device.
- In order to avoid a hazard for very young children, this device should be installed so that the lowest
heated rail is at least 600 mm above the floor.
- Prevent children from climbing on the device.
- For safety reasons, it is strictly forbidden to top up unmixed devices. If necessary, contact the manu-
facturer’s After-Sales Service or a qualified technician.
- Any intervention on the electrical parts must be performed by skilled staff.
- Do not insert objects or paper in the device.
- Upon first warming, a slight smell may appear, due to the evacuation of compounds used during the
device’s manufacturing.
- The casing may be hot, even when the device is off.
GB
