7
Install Oven
1. Using 2 or more people, lift oven partially into cabinet cutout.
Use the oven opening as an area to grip.
NOTE: Push against seal area of oven front frame when
pushing oven into cabinet. Do not push against outside
edges.
2. Push against seal area of front frame to push oven into
cabinet until shipping feet almost contact cabinet.
3. On models with shipping feet, use a Phillips screwdriver to
remove screws attaching the shipping feet.
4. Push oven completely into cabinet and center oven into
cabinet cutout.
5. Securely fasten oven to cabinet using the # 8–14 x 1" screws
(2 for single oven, 4 for double oven) provided. Insert the
screws through holes in mounting rails. Do not overtighten
screws.
6. On some models, the oven vent is taped to the side of the
oven. See the following instructions to install.
■ Insert the vent tabs (B) into slots (A) in the oven frame.
■ With one # 8–18 x
³⁄₈" screw (C) for each side of the vent,
fasten vent securely to the oven.
7. Slide top end of each trim piece upward onto oven side rails.
A. Shipping foot
WARNING
Excessive Weight Hazard
Use two or more people to move and install oven.
Failure to do so can result in back or other injury.
A
A. Mounting rail
B. Insert screw.
A. Oven frame slot
B. Vent tab
C. # 8–18 x ³⁄₈" screw
D. Oven vent
A
B
A B
C
D
