Installing your hob in complete safety
When several heating zones are used
simultaneously over long periods of time, or in
hot climatic conditions, we recommend that
openings be made in the side of the unit near
the air escape to allow the hot air to be
evacuated more easily.
mini 40 cm2
mini 40 cm2
mini 4 mm
For example 8 x 5cm
Oven in the HIGH or LOW position
mini 5 cm
Kit d'isolation (SAV)
mini 4 mm
Oven in the LOW position
Ensure that the unit crossbar does not block the air
passage, make a bevel if necessary.
Compulsory
isolation kit available
from the after-sales
service 75X1652
Your induction hob must always be adequately ventilated.
Make sure that the air inlet through the fan grid at the back is not obstructed.
If these recommendations are not adhered to, the hob may overheat, switch into the "safety" position
and stop temporarily (F7 or a series of small lines can be seen on the display)
The hob must not be fitted above a washing machine, a refrigerator or a deep-freeze.
Above a cupboard or drawer unit Above an oven of the same
make
Above an oven of a different make
