If your hob is placed above your oven (see "Choice of Installation") thermal
protectors prevent it being used when the oven is being
pyro-cleaned .
3
Using your hob in complete safety
We have designed this hob for private use in homes.
With a view to constantly improving our products, we reserve the right to make any changes to their
technical, program or aesthetic features connected with their technical evolution.
These hobs are exclusively designed for cooking drinks and foodstuffs and contain no asbestos based
components.
We suggest that you should periodically check that there are no objects (glass, paper, etc.) that could
obstruct the air inlet under your induction hob (See fitting)
HOB safety
• A sensor continuously monitors the
temperature of the components of your hob.
The power output by the hob will automatically
be reduced if this temperature becomes
excessive.
• You only have to remove the recipient from the
hob to stop power instantaneously. Push the "Off"
touch control to turn off the heating zone
completely.
SAUCEPAN safety
Each unit is equipped with a sensor that conti-
nuously
monitors the temperature of the bottom of the
pan, so that overheating is impossible (empty
saucepan, etc.).
METALLIC OBJECT safety
A small object such as a fork, spoon or a ring
placed on your induction hob by itself is not
detected as a pan. The display flashes and there
is no output power.
Residual heat indicator
After intensive use, the cooking zone may remain
hot for several minutes.
The letter “
H” H” is displayed during this period. Do
not touch the zones concerned
Automatic-Stop
Automatic stop is a safety function for your hob. It
starts up automatically if ever you forget to turn off
your cooking.
The letter A is displayed for the heating zone
concerned and the hob will bleep for about 2 mi-
nutes. The A will continue to be displayed until any
control of the zone in question is touched. The hob
will then bleep twice to confirm your action.
Power consumed The heating zone
goes out automatically
after
Between 1....4 8 hours
Between 5....7 2 hours
Between 8....Max 1 hour
