7
1”
a
1”
F i g u r e 3
E E E N N E EN N
ANTI-TIP STABILITY DEVICE INSTALLATION INSTRUCTIONS
1. The anti-tip bracket have to be attached to rear wall, as show in F i g . 3 , before backguard installation. The dimension
for the bracket location from the fl oor have to be determined after range legs have been adjusted to the proper
installation height as show in the installation instructions and the range has been levelled.
2. Measure from the fl oor to the bottom of the anti-tip location on the back of the range.
3. Locate the two anti-tip bracket holes (dimension of the holes 15/64”(6mm)) on the wall at the measured dimension
plus 5/32”(4mm). The two anti-tip have to be placed close to the side of the range location (recommended dimension
is 1”(25,4mm from the sides).
4. Fix the two bracket on the wall.
5. Install backguard, as shown at the next part (see Install backguard chapter).
6. Adjust range legs 5/16”(8mm) shorter than the proper installation height. Slide in then the range against the wall.
Adjust range legs to the proper installation height.
S E RV I C E & M A I N T E N A N C E I N S T R U C T I O N S
R e p l a c e m e n t Pa r t s .
Authorized replacement parts may be used in performing service on the appliance. Replacement parts are available
from factory authorized part distributors.
S e r v i c e a n d m a i n t e n a n c e o n ly t o b e c a r r i e d o u t by a n a u t h o r i s e d p e rs o n .
A good maintenance of the induction cooker requires a regular cleaning, care and servicing.
The operator has to ensure, that all components relevant for safety are in perfect working order at all times.
The cooker should be examined at least once a year by an authorized technician.
Do not open the induction
unit, dangerous electric
voltage inside.
WARNING
The cookers may only be opened by authorized personnel.
N O N WO R K I N G A P P L I A N C E S
Before calling the After Sales Service, check that the appliance is connected or that the main switch is activated. After,
call the After Sales Service. The faults must be checked by a skillfull technician.
R e m a r k : the appliance is equipped with a safety thermostat, adjusted at a certain temperature. In case it reaches a
higher temperature, the appliance switches off.
