BOOSTER FUNCTION
The purpose of the booster function is to give more power to a determined area in order to reduce the necessary cooking
time.
This function is activated by push and turning the knob clockwise from position 0 (off) to the fi nal position (* fi g. 13). The
symbol [P] appears on the display, meaning that the booster function is activated.
The Booster function has a maximum duration of 10 minutes. The area concerned then returns to level [9].
The Booster function ends before this time when:
- a lower power level is set;
- the pan is removed;
- there is overheating of the appliance or of the heating area.
The Booster function has precedence over the “Heat-up” function. This means that, if the heat-up function has been
activated in an area at the time of activating the Booster function, the heat-up function will be interrupted.
RECOGNIZING THE PRESENCE OF A PAN
Each cooking area is designed to operate with specifi c pans for induction cooking, having a diameter just smaller than
the diameter of the chosen cooking area.
If the pan is not suitable, the display for the area shows the symbol indicating absence of the pan (U) and the appliance
does not start up.
This prevents the appliance being switched on until a container is placed on the cooking area, or until a container suitable
for induction is used. If the container is removed during operation, the area is switched off.
The duration of pan recognition is 30 seconds; if no suitable container is used on the cooking area during this time, the
area is switched off.
RESIDUAL HEAT INDICATION
If the cooking area is still very hot, even though it is switched off, the symbol H appears on the display.
“HEAT-UP” FUNCTION
The Heat-up function, or quick heating, is available on each cooking area. This means that for a well defi ned time the
cooking area works at maximum power and at the end of this time the power is automatically brought to the set level. In
this case the duration depends on the set power level.
The Heat-up function is activated by push and turning the knob anticlockwise from position 0 to the fi nal position (* fi g.
1a). As soon as the control is turned to the left, a letter [A] is shown on the display for the area. After it has been activated
you must set a power level to continue cooking within 5 seconds; if this is not done, the Heat-up function is interrupted.
KEY-LOCK FUNCTION
The Key-lock function is useful if there are children at home. However, it is always advisable for an adult to be present
when the appliance is in operation. When the Key-lock function is activated all the cooking areas are switched off and
they cannot be switched on accidentally.
The Key-lock function is activated, with the knobs in position 0, by push and turning the controls 1 or 2 for 4 seconds in
an anticlockwise direction.
The letters [L][L][L][L] appear on the display. The Key-lock function is deactivated by repeating the same operation. If a
knob is turned when the key-lock function is active, the letters [L][L][L][L] appear on the display.
HEATING FUNCTION 150°F
Turn the knob (A) in a clockwise direction. Between the off area position (0) and the power position (1) there is the position
"
|
" which identifi es the function for heating food to 150°F.
DISPLAY
A display is associated with each cooking area.
-Set power level: (1-9)
-Food heating 65° (U)
-Booster: (P)
-Heat-up: (A)
-Residual heat: (H)
-Pan absent or not suitable: (U)
-External error: (E)
-Fault: (F)
-Key-lock function: [L][L][L][L]
