21
E E E N N E EN N
KEYS
00 BLACK
11 BROWN
22 RED
33 WHITE
44 YELLOW
55 YELLOW-GREEN
66 GREY
AA BLUE
C ELECTRICAL IGNITION TRASFORMER
DS1 ELECTRONIC CONTROLLER
EL OVEN VALVE
EL1 GRILL VALVE
K1 EARTH WIRE FOR TERMINAL BOARD
K2 EARTH WIRE LOWER RESISTANCE
K3 EARTH WIRE FOR OVEN FAN
K4 EARTH WIRE CIRCULAR RESISTANCE
K5 EARTH WIRE UPPER RESISTANCE
K6 EARTH WIRE OVEN LAMP 1
K7 EARTH WIRE OVEN LAMP 2
K8 EARTH WIRE ROTISSERIE
K9 EARTH WIRE COOLING FAN
K10 EARTH WIRE SELECTOR
K11 EARTH WIRE OVEN THERMOSTAT
K12 EARTH WIRE PROGRAMMER
K13 EARTH WIRE GRILL
K14 EARTH WIRE EL. HOTPLATE
K15 EARTH WIRE APPLIANCE CHASSIS
K16 EARTH WIRE BARBECUE
K17 EARTH WIRE FRYER
L1 PHASE 1
L2 PHASE 2
KEYS
OL1 OVEN LAMP
OL2 OVEN LAMP
M TERMINAL BOARD
MA ELECTRICAL IGNITION MICROSWITCH
MD GRILL MICROSWITCH
MG ROTISSERIE
MP DOOR MICROSWITCH
N NEUTRAL
P
MINUTE COUNTER/PROGRAMMER
MINUTE COUNTER/CLOCK
PE INDUCTION ZONE
R1 UPPER HEATING ELEMENT
R2 LOWER HEATING ELEMENT
R3 GRILL HEATING ELEMENT
R4 CIRCULAR HEATING ELEMENT
R5 BARBECUE HEATING ELEMENT
RE ENERGY REGULATOR
S1 OVEN WARNING LIGHT
S2 MAINS POWER WARNING LIGHT
S3 GRILL WARNING LIGHT
SP SPARKING PLUG
ST FAN FAILURE LIGHT
T GRILL THERMOSTAT
TF OVEN THERMOSTAT
TR FRYER THERMOSTAT
TS SAFETY THERMOSTAT
TST SAFETY THERMOSTAT COOLING FAN
TT COOLING FAN THERMOSTAT
V OVEN FAN
VT COOLING FAN
GROUND
E L E C T R I C A L S K E T C H E S
