Version 2.1
EN-3004 (4 Channel) EN-1502 (2 Channel)
Class Class-AB Class-AB
Power 1800 Watts 1000 Watts
Frequency Response 20Hz - 20kHz 20Hz - 20kHz
Dimensions 336mm (13-1/4”) x 200mm (7-
7/8”) x 51mm (2”) 256mm (10-1/16”) x 200mm (7-
7/8”) x 51mm (2”)
RMS Power Ratings 60 Watts x 4 @ 4 Ohms 1% THD+N
75 Watts x 4 @ 2 Ohms 1% THD+N
150 Watts x 2 @ 4 Ohms Bridged
1% THD+N 60 Watts x 2 @ 4 Ohms 1% THD+N
75 Watts x 2 @ 2 Ohms 1% THD+N
150 Watts x 1 @ 4 Ohms Bridged
1% THD+N
Signal to Noise Ratio >50 dB >50 dB
High and Low Pass
Crossover 12dB per Octave 12dB per Octave
Crossover Range 50Hz – 250Hz 50Hz – 250Hz
Low Level Input Range 0.35 Volts to 10 Volts 0.35 Volts to 10 Volts
High Level Input Range 1 Volt to 30 Volts 1 Volt to 30 Volts
Minimum load
impedance 2 Ohm stereo and 4 Ohm bridged 2 Ohm stereo and 4 Ohm bridged
EN-3001 (Monoblock)
Class Class-AB
Power 1200 Watts
Frequency Response 20Hz - 400Hz
Dimensions 336mm (13-1/4”) x 200mm (7-
7/8”) x 51mm (2”)
RMS Power Ratings 200W x 1 @ 4 Ohms 1% THD
300W x 1 @ 2 Ohms 1% THD
Signal to Noise Ratio >50 dB
High and Low Pass
Crossover 12dB per Octave
Subsonic Filter 12dB per Octave
Low Pass Crossover
Range 50Hz – 400Hz
Subsonic Crossover
Range 10Hz – 40Hz
Bass Boost @ 45Hz 0 to +18dB
Low Level Input Range 0.35 Volts to 10 Volts
High Level Input Range 1 Volt to 30 Volts
Minimum load
impedance 2 Ohm
AMPLIFIER SPECIFICATIONS
NOTE: ENCOUNTER
AMPLIFIER SERIES
HAVE A MINIMUM LOAD
IMPEDANCE OF
2 OHM PER CHANNEL
4 OHM BRIDGED
General
Power
Requirements +12 V DC (negative
ground)
Operating Voltage 10.5 – 16V
Minimum
Recommended-
Power/Ground
Cable Size 8 Gauge (AWG)
Recommended
inline fuse size 8 Gauge Cable - 40A
4 Gauge Cable - 80A
