Cybex 790T Treadmill - Manuel (Page 7)

Manuel d’utilisation de la Cybex
7
Autocollants d'avertissement
Pour remplacer des autocollants usés ou endommagés, utilisez l'une des méthodes suivantes :
rendez-vous sur www.cybexintl.com pour l'achat de pièces en ligne. Faxez votre commande au 1
508 533 5183 ou contactez le Service à la clientèle Cybex en composant le 1 888 462 9239. Si vous
ne résidez pas aux États Unis, composez le +1 508 533 4300. Pour repérer l'emplacement ou les
numéros de pièces figurant sur les autocollants, consultez la liste des pièces et la vue éclatée sur
www.cybexintl.com .
Les autocollants d’avertissement indiquent une situation potentiellement dangereuse qui peut
entraîner des blessures graves, voire mortelles si les mesures de sécurité ne sont pas respectées.
Les autocollants de mise en garde signalent une situation potentiellement dangereuse qui, si elle
n’est pas évitée, risque d’entraîner des blessures mineures ou moyennement graves.
Les schémas figurant après les autocollants indiquent l’emplacement de chaque autocollant.
