Chapter 5 : FRONT PANEL DISPLAY MENUS DESCRIPTION (continued) OCTO VUE / QUATTRO VUE
PAGE 30
3 [OUTPUT] + ENTER.
3-1 [Output status] + ENTER.
Indicates the status of the output.
3-2 [Output format] + ENTER.
Select one of the available output formats with + ENTER.
For the MAIN outputs: For the PREVIEW output:
• [852x480 16/9] • [1024x768 4/3]
• [800x600 4/3]
• [1280x720 16/9]
• [1024x768 4/3]
• [1280x768 16/9]
• [1366x768 16/9]
• [1280x1024 4/3]
• [1400x1050 4/3]
• [1920x1080 4/3]
• [1600x1200 4/3]
NOTE: For fixed pixels display devices (DMD, LCD, PLASMA…), always select the output format
corresponding to the native resolution of the display device. Thus, the display device will not have to
scale the image and the result will be better.
3-3 [Output rate] + ENTER.
For the MAIN outputs: For the PREVIEW output:
• [50 Hz]: 50 Hz output frame rate • [60 Hz]: 60 Hz output frame rate
• [60 Hz]: 60 Hz output frame rate
• [72 Hz]: 72 Hz output frame rate
• [75 Hz]: 75 Hz output frame rate.
3-4 [Output sync] + ENTER.
Select the Output Sync. type with + ENTER.
For the MAIN & PREVIEW outputs:
• [H&V]: H & V Separate Sync.
• [COMP]: Composite Sync.
• [SOG]: Sync On green.
3-5 [Type of screen] + ENTER.
Select an item with + ENTER.
For the MAIN & PREVIEW outputs:
• [screen 4/3]: If your image is displayed on a 4/3 wall mounted projection screen shape.
• [screen 16/9]: If your image is displayed on a 16/9 wall mounted projection screen shape.
NOTE: Available only in case of 4/3 output format.
3-6 [Test pattern] + ENTER.
Select an item with + ENTER.
For the MAIN & PREVIEW outputs:
• [no pattern] No test pattern is displayed.
• [centering]: Displays onto the output a centering pattern (for position and size adjustments).
• [color bar]: Displays onto the output a color bar pattern.
• [grey scale]: Displays onto the output a grey scale pattern.
• [grid]: Displays onto the output a grid pattern.
• [burst]: Displays onto the output a burst pattern.
