English - 53 -
DVD Player
Side AV Input
Audio Cable
(Not supplied)
Side AV
Connection cable
(supplied)
Si
de
A
V
To RED & WHITE inputs
Audio Connection
Video Connection
HDMI
inputs
Scart socket
DVD player
YPbPr to PC
cable (optional)
Remote Control Handset
Inserting Batteries
Remove the battery cover located on the back of •
the handset by gently pulling backwards from the
indicated part.
Insert two
• AAA/R3 or equivalent type batteries
inside. Observe the correct polarity (+/-) when
inserting batteries and replace the battery cover.
Note: Remove the batteries from the remote control
handset when it is not to be used for a long period.
Otherwise it can be damaged due to any leakage of
batteries. Remote range is approximately 7m/23ft.
Switching On/Off
To Switch the TV On
Connect the power cord to the 220-240V AC, 50 •
Hz.
Press STANDBY touch button. Then the standby
•
LED lights up.
To switch on the TV from standby mode either:
•
Press the “ • ” button, P+ or P- or a numeric button
on the remote control.
Press the control switch right side of the TV. The TV
•
will then switch on.
Note: If you switch on your TV via P+ or P- buttons on
the remote control or on the TV set, the programme
that you were watching last will be reselected.
By either method the TV will switch on.
To Switch the TV Off
Press the “ • ” button on the remote control or hold
the control switch on the Tv until shut down , so the
TV will switch to standby mode.
To power down the TV completely, unplug the
•
power cord from the mains socket.
Note: When the TV is switched to standby mode, the
standby LED can blink to indicate that features such
as Standby Search, Over Air Download or Timer is
active.
Input Selection
Once you have connected external systems to
your TV, you can switch to different input sources.
Press “ SOURCE” button on your remote control
consecutively for directly changing sources.
Note : YPbPr mode can be used only when you
connect a device that has a YPbPr output through the
PC input with YPbPr to PC cable (not supplied).
