4 - Installation Instructions
STEP 1
Install the backsplash (if provided) by the three screws on the
back and the toe kick
3” 9”
STEP 2
Slide the rangetop top into place.
STEP 3
Two clamp brackets are provided with your unit.
After rangetop has been installed into the countertop, install the
brackets on the burner box as shown.
step A place the clamping screws into brackets
step B attach brackets by using the attachment screws on the
selected location of burner box, tighten screws just
enough to hold brackets in place
step C position brackets so that they are with the clamp screw
in contact with the counter top bottom
step D tighten attachment screws securely.
step E check that the front edge of the rangetop is parallel
to the front edge of the countertop tighten the screw
clamping against the countertop.
DO NOT OVER TIGHTEN
