EN
9
3 - Installation Information
WARNING
• Excessive Weight Hazard
Use two or more people to move and install rangetop.
Failure to do so can result in back or other injury.
• Cut Hazard
Beware of sharp edges. Use the polystyrene ends when
carrying the product. Failure to use caution could result in
minor injury or cuts.
CHOOSING RANGETOP LOCATION
Carefully select the location where the rangetop will be placed.
The rangetop should be located for convenient use in the
kitchen, but away from strong drafts.
Strong drafts may be caused by open doors or windows, or by
heating and/or air conditioning vents or fans.
IMPORTANT NOTE
When installing against a combustible surface, a minimum
riser is required for a the rangetop, Follow all minimum
clearances to combustible surfaces shown in the illustration
on the previous pages.
To eliminate the risk of burns or fire by reaching over heated
surface units, cabinet storage space located above the surface
units should be avoided. If cabinet storage is to be provided,
the risk can be reduced by installing a rangetop hood that
projects horizontally a minimum of inches beyond the bottom
of the cabinets.
TOOLS WILL YOU NEED
Remove packaging materials and literature package from the
cooktop before beginning installation.
Remove Installation Instructions from the literature pack and
read them carefully before you begin
MATERIALS PROVIDED
Appliance
pressure
regulator
Flare union Gasket
Fixing brackets
MATERIALS REQUIRED (not provided)
Shut-Off Valve Pipe Fittings
5-foot maximum length, 5/8” O.D. CSA-approved flexible
metal gas supply (3-foot maximum length in Massachusetts only)
NOTE: Purchase new flexible line; do not use previously used
flexible gas line.
Joint Sealant
