4
ASSEMBLY INSTRUCTIONS
1. Find a clean, level place to begin the assembly of your Billiard Table. The table will be assembled upside down
and then turned over on its legs once the assembly completed. This game table is heavy, and turning it over will
require at least four strong adults.
2. Remove all the parts from the box and verify that you have all of the listed parts as shown on the parts list page.
Carefully cut or tear the four corners of the box so that the bottom of the box can be used as your work surface.
FIG.1
3. Apply the Glue (#18) to the edge of the Inside Legs - B (#3) as shown in FIG.1, and then attach to the Inside Legs
-A (#2) using four Screws (#42) per Inside Leg - B.
FIG.2
4. Apply the Glue (#18) in the grooves of the Inside Legs (#2 & #3) as shown in FIG.2. Attach the Leg Bases (#4) to
the grooves using two Screws (#42) per Leg Base. See FIG.2 & 2A.
Note: Do not place the wrong surface of the Leg Base (#4), the pre-installed Nut (#40) is visible when you
assemble the Leg Leveler (#39).
5. Screw the Leg Levelers (#39) into the Leg Bases (#4).
FIG. 1
FIG. 2
3
3
2
18
18
42
42
4
39
40
4
FIG. 2A
