Instruction, Remote control key functions – Curtis LEDVD1966A Manuel d'utilisation
Page 7
11
(1) POWER button:
Switches the set on from power on or off .
(2) EPG/ button: Enter Electronic Program Guide;
Press in DVD source Load/ Eject DVD disk.
(3) MUTE button: Press to eliminate or restore the TV sound.
(4) P.MODE button:
Press to select preset picture mode
.
(5) S.MODE button:
Press to select
Sound mode button.
(6) ASPECT button:
Press to select picture mode 4:3, 16:9 etc.
(7)
DISPLAY
button
:
Press to display current status,
TV channel,
input source.
(8) Numerical buttons:
Press number buttons for direct access TV channels.
(9) button:
Press to return to previous channel
.
(10) 10+/- button: Direct input numerical button
for 2 digit or 3 digit program.
(11) MENU button: LED menu selection.
(12) EXIT button: Exit the OSD menu (On-screen display).
(13) SOURCE button:
Press to display all possible input sources
(14) SLEEP button: Sets the sleep timer。
(15) " "button: When OSD menu is on, press this button
to move the selection focus up or change settings.
(16) " "button: When OSD menu is on, press this button
to move the selection focus down or change settings.
(17) " "button: When OSD menu is on, press this button
to move the selection focus left.
(18) " "button: When OSD menu is on, press this button
to move the selection focus right.
(19) " ENTER "button: Press the button to confirm the operation.
(20) CH- button: Changes the channels down.
(21) CH+ button: Changes the channels up.
(22) VOL- button: Adjusts the volume down.
(23) VOL+ button: Adjusts the volume up.
REMOTE CONTROL KEY FUNCTIONS
INSTRUCTION
10
REMOTE CONTROL KEY FUNCTIONS
INSTRUCTION
(24) MTS button: Press to select the audio channels.
(25) CC button: Press to display the closed caption.
(26)
button: Press to play or pause the disc under DVD mode.
(27) button:
(28) FAV+/ button: Changes the Favorite channels up;
(29) FAV-/ button: Changes the Favorite channels down;
(30) FAV/ button:
Add
/
Erase
function
for
f
avorite;
(31) CH LIST/ button: TV Channel List button;
(32) button:Single-step video file playback.To resume normal
playback , press play button .
(33) GOTO button: DVD start playing from the desired time.
Press time and enter time
.
The unit starts playing
from you selected.
(34) A-B button: Press to AB playback the DVD play.
(35) PROG button: To select the DVD program playback.
(36)
TITLE: During a DVD disc playback,
press to go to title menu if the disc contains title.
(37)
AUDIO button: Change the DVD audio mode:
left, right, mono, stereo.
(38)
SUBTITLE button: Press the button to select
different captions.
(39)
ANGLE button: Select different angle of DVD.
(40)
D.SETUP button: Display the DVD SETUP menu.
(41)
D.MENU button: Display the DVD MENU.
(42)
INTRO
button:
It will achieve navigation
function when play VCD disk
.
While the disk is working, press INTRO button.
Play each clip by 3 sec(Video Discs) .
- If started the disc menu, preview will not function.
- If the current track started over 3 sec, this function
will start from next track.
(43)
REPEAT button: Repeat playback the DVD play.
